SD32 transmission assy 175-15-00226

Parts are available, but not limited to, for following models:
SHANTUI Bulldozers: SD08, SD13, SD16, SD22, SD23, SD32, and SD42.
KOMATSU Excavators: PC130-7, PC200-7, PC200-8, PC220-7, PC220-8, PC240-7, PC240-8, PC270-7, PC270-8, PC300-7, PC300-8, PC360-7, PC400-7, PC400-8, PC450-7, PC450-8.
KOMATSU Bulldozers: D53A-17, D65A-8, D85A-18, D85A-21, D155A-2.
KOMATSU Wheel loaders: WA250-1, WA320-3, WA380-3, WA420-3, WA470-3, WA500-3.
CUMMINS Engines: 4BT, 6BT, 6CT, 6L, 4ISDE, 6ISDE, 4ISBE, 6ISBE, 6ISLE, NT855, N14, M11, L10, K19, K38.
SANY Excavators: SY65C, SY75C, SY135C, SY195C, SY215C, SY225C, SY365H, SY465H, etc.
SANY Trucks: SRT55, SRT95.
TEREX Trucks: TR50, TR60, TR100, etc.
WEICHAI ENGINE SERIES: WP12, WP10, WP6, WP4, WD615, 226series, WT615, WD618, R6160, X6160, etc.

LIUGONG: CLG8128H, CLG862, CLG862-LNG, CLG835, ZL50CN, 856IV, ZL50D, CLG842IV, CLG816A, CLG812C, CLG833, CLG856H, LG823D, CLG836-I, ZL50CNX, ZL50CN-LNG, CLG825C, CLG820C-I, CLG820C, CLG818C, CLG816C, CLG842III, CLG842, CLG877III, CLG855N, CLG899III, ZLG30G, ZLG40G, ZLG50G, CLG852, ZL50CX, ZL40B, ZL30E, ZL100C, CLG856, CLG899, CLG816, CLG836, CLG855, CLG856III, CLG888III, CLG888, ZL50C.

175-15-42890

SD23 Transmission parts:

SD23 Transmission Gear and Shaft Related Parts
Part No.	Part Name	Part No.	Part Name	Part No.	Part Name
154-15-41002	transmission assy	154-15-42321	carrier	154-15-42131	shaft
154-15-42111	shaft	07043-70108	plug	07018-11205	seal ring
154-15-42230	gear	154-15-42420	gear	06000-06019	bearing
154-15-42160	collar	561-15-49410	bearing	04071-00145	snap ring
154-15-42241	gear	561-15-32590	washer	154-15-42270	hub
04064-07025	snap ring	154-15-42521	shaft	07018-12205	seal ring
06000-06922	bearing	04260-00635	ball	144-15-11290	seal ring
06000-06014	bearing	154-15-42940	cover	154-15-42210	gear
04065-01104	snap ring	01010-51030	bolt	154-15-42150	collar
154-15-42171	collar	01643-31032	washer	06000-06922	bearing
154-15-42190	coupling	154-15-42651	gear ring	154-15-42220	gear
07000-05055	O-ring	568-15-12950	snap ring	04064-09530	snap ring
154-15-42180	holder	154-15-42630	gear ring	234-21-12180	nut
01051-51800	bolt	154-15-42620	gear ring	175-15-42220	pin
06000-06216	bearing	175-15-69510	snap ring	234-21-12190	plate
04701-00140	snap ring	154-15-42610	gear ring	234-21-12210	plate
07012-10100	seal	175-15-12780	pin	01010-50814	bolt
154-15-41171	housing	175-15-42880	spring	154-15-42310	carrier
07043-70312	plug	23A-15-12960	spring	154-15-42410	gear
144-15-21191	bolt	198-15-22810	disc	154-15-49410	bearing
145-14-11570	washer	426-15-12720	plate	569-15-32560	thrust washer
07000-05250	O-ring	154-15-41140	housing	154-15-42510	shaft
154-15-42331	carrier	154-15-42750	piston	04260-00635	ball
154-15-42440	gear	175-15-59250	seal ring	154-15-42930	cover
561-15-49410	bearing	582-15-19240	seal ring	04020-00616	dowel pin
561-15-32590	washer	154-15-41130	housing	568-15-12950	snap ring
154-15-42530	shaft	04020-01434	dowel pin	154-15-41270	pin
04260-00635	ball	175-15-42880	spring
154-15-49510	snap ring	154-15-41290	pin
154-15-49260	seal ring	421-15-12910	spring
175-15-69230	seal ring	424-15-12710	disc
154-15-42641	gear ring	424-15-12720	plate
175-15-12780	pin	175-15-62730	piston
175-15-42880	spring	195-15-49210	seal ring
234-15-15230	spring	113-15-29250	seal ring
198-15-22810	disc	154-15-42840	housing
426-15-12720	plate	566-15-41320	plug
426-15-12750	piston	195-15-49240	seal ring
426-15-19220	seal ring	04020-01228	dowel pin
426-15-19210	seal ring	04020-00616	dowel pin
154-15-41160	housing	01010-51235	bolt
145-14-11320	plug	01643-31232	washer
04020-01434	dowel pin	175-15-62830	collar
175-15-62750	piston	125-15-29510	ring
175-15-59250	seal ring	154-15-43130	cage
426-15-19210	seal ring	175-15-11230	plug
234-15-15230	spring	154-15-49210	seal ring
154-15-41150	housing	19M-15-19260	seal ring
569-15-41310	sleeve	01010-61435	bolt
07000-73022	O-ring	01643-31445	washer
175-15-62760	piston
155-15-12811	seal ring
582-15-19240	seal ring

SHANTUI PUMPS AND VALVES
Item	Part Name	Part No.	Model No.
1	Steering Valve	16Y-76-22000	SD16
2	Control Valve Ass'y	16Y-75-10000	SD16
3	Lubrication Valve Ass'y	16Y-75-20000	TY160,SD16
4	Safety Valve	16Y-76-23000      (144-49-16101)	TY160,SD16
5	Valve	16Y-11-30000	TY160,SD16
6	Hydraulic Control Valve	16Y-60-11000	TY160,SD16
7	Valve Ass'y	16Y-60-05000	SD16,SD13
8	Steering Valve Ass'y	154-40-00082	SD22,SD23,TY230
9	Transmission Valve Ass'y	154-15-35000	TY220,SD22
10	Blade Lift and Tilt Control Valve Ass'y	701-34-11002	TY220,SD22
11	Lubrication Valve Ass'y	154-15-34000	TY220,SD22
12	Main Relief Valve Ass'y	701-30-51002	TY220,SD22
13	Valve Ass'y	154-49-51100	SD22
14	Ripper Control Valve Ass'y	701-32-27001	TY220,SD22
15	Relief Valve Ass'y	195-13-16100	SD22,SD32
16	Valve Ass'y	175-13-26401	SD22,TY320,SD32
17	Servo Valve Ass'y for Blade Lift	702-12-13001	SD22,SD32
18	Servo Valve Ass'y for Blade Tilt and Ripper Control	702-12-14000	SD22,SD32
19	Universal Joint Ass'y	16Y-12-00000	SD16
20	Universal Joint Ass'y	154-20-10002	SD22
21	Universal Joint Ass'y	16T-12-00000	SD16T
22	Universal Joint Ass'y	175-20-30000	SD32
23	Pump Ass'y	07446-66103	SD32,TY320
24	Steering Pump Ass'y	07440-72202	SD32,TY320
25	Transmission Pump Ass'y	07433-71103	SD32,TY320
26	Transmission Pump Ass'y	07443-71103	SD32
27	Pump Ass'y	705-51-30190	SD23
28	Hydraulic Pump Ass'y	07444-66103	SD22,TY220
29	Steering Pump Ass'y	07436-72202	SD22,TY220
30	Transmission Pump Ass'y	07432-71203	TY220,TY160,SD16
31	Pump Ass'y	705-21-32051	SD22,SD23
32	Hydraulic Pump Ass'y	16Y-61-01000	SD16,TY160
33	Steering Pump Ass'y	16Y-76-06000	SD16,TY160
34	Transmission Oil Pump	16Y-75-24000	SD16,TY160
35	Pump Ass'y	16T-70-10000	SD16T,TY160, Komatsu D60
36	Hydraulic Pump Ass'y	10Y-61-04000	SD13,TY130
37	Steering Oil Pump Ass'y	10Y-76-11000	SD13,TY130
38	Transmission Pump	10Y-75-12000	SD13,TY130
39	Scavenging Pump Ass'y	175-13-23500	SD22,SD23,SD32
